I got my Saiga-12 fixed up. I haven’t machined the receiver for the new buttstock, but I got the new trigger guard and fire control group installed. The buttstock will be very easy compared to this other stuff.
I learned a lot from the people at Saiga-12.com. They are extremely helpful and patient.
Some tips for people who do their own conversions:
1. Go to the forum at Saiga-12.com for help. Those guys are fantastic.
2. Don’t forget to take out whatever is retaining the trigger and hammer pins before trying to tap them out of the receiver.
3. Use a center drill (Google it) to start the holes when you drill out the rivets on the Hillary-style trigger guard and the old trigger group. Use a drill press or milling machine to start the holes on the trigger guard rivets, if possible.
4. When you take out the bolt hold open lever and spring, make sure you sketch the location and orientation of the parts. They make no sense, and if you look for pictures online, you’ll find stuff that’s misleading.
5. When you put the gun back together, install the safety lever first. Trust me.
6. If you have a Tromix fire control group, the big V-shaped retaining spring for the hammer and fire control group pins should be oriented with the point of the V toward the back of the gun. If it won’t click into place, open the loop at the point of the V slightly and try again.
7. When you install a Tromix fire control group, the hammer goes in backwards.
8. To reinstall the BHO lever and spring, do this. Drop the trigger in. Put the pin in it. Make a 1/8″-long (or shorter) bend in the short end of the spring, so it catches the little projection on the lever. Drop the spring into the receiver. Run the pin through it, into the far side of the receiver. Drop the BHO lever in. Make yourself a tool from a paper clip (don’t use a dental pick). Straighten the clip and make a tiny hook at one end, just big enough to hold the spring wire. Make a bigger hook at the other end, big enough to go around a screwdriver shaft. Catch the spring end in the little hook, put a screwdriver in the big hook, and use the screwdriver shaft as a handle to pull the spring end toward the muzzle of the gun. You should be able to drop the spring end onto the projection on the lever. This tip is worth its weight in gold. You don’t need the BHO lever, so you can throw it out if you want.
I find it amusing that “BHO” stands for “bolt hold open” as well as B. Hussein Obama.
9. Don’t worry about scratching the finish on the gun, because it’s no good and will need to be replaced. Use aluminum oxide 120 grit to blast the old crap off, and then coat the gun with Norrell’s moly resin or Brownell’s aerosol equivalent. You can use Norrell’s on the inside of the receiver, because it’s too thin to interfere with moving parts. Not sure about Brownell’s. Glass bead blasting will result in a finish that falls off.
That’s about it. I learned some of this stuff from experience and some by begging and Googling.
Now it’s time to relax and have a healthy dinner of ham hocks, fried apples, and mustard greens.
Pre-conversion:
Post-half-conversion:
